Body:
Description:
- Column construction free of base- and support framework
- Micro-processor control ensures synchronisation and self-monitoring of all safety functions
- Measurement of lifting height via non-contact, maintenance-and wear-free inductive sensors
- Pinch point protection by audible warning signal
- Excellent bending and torsional strength of lifting columns
- Columns turned by 45° and asymmetrical support arms offering greater door opening angle at the vehicle
- Short support arms 180° swivable with large reach, pick-up points can be reached quickly
- Low-profile support arms
- Operating panel with robust foil keypad, integrated into column
- Additional control unit mounted to opposite column (option)
- Maintenance-free synthetic load and safety nut assembly
- Long-term lubrication for spindles and nuts
- Generous lifting height for upright access for even the tallest personnel
- Excellent corrosion protection by powder coating
- 5 years warranty on spindles and load nuts (Please pay attention to our extended warranty terms listed in the operating instructions)
- Powder coating: blue, RAL 5010/dark grey, RAL 7016
Contenu de la livraison:
- 2 columns with operating panel
- 2 long support arms, 2 short support arms
- Support discs with plug-in system
- Overhead cable tray
- Spindle oil (0.25 l)
- Operating instructions
- Packaging included
